NUC-TGU
11th Gen Intel Tiger Lake Fanless NUC Slim System
- Intel® 11th Tiger Lake-U Processor
- Intel® Iris® Xe Graphics
- Single Memory Socket, Max. Up to 32GB DDR4 3200
- Dual Display, HDMI 2.0b
- Dual Intel® Gigabit Ethernet, 2.5GbE, 1GbE
- Triple M.2 Slot, Key-E/B/M for Wi-Fi, LTE, SSD, I/O module
- Supports iAMT, Kensington Lock
- Default dTPM 2.0, Mounting Kit
- Processor
- Intel® Core™ Processor i7-1165G7 (15W)
- Intel® Core™ Processor i5-1135G7 (15W)
- Intel® Core™ Processor i3-1115G4 (15W)
- Intel® Core™ Processor i7-1185G7E (15W)
- Intel® Core™ Processor i5-1145G7E (15W)
- Intel® Core™ Processor i3-1115G4E (15W)
- System Memory: 1 x 260-pin DDR4 SODIMM Socket, Supports Up to 32GB DDR4 3200MTs SDRAM
- I/O Chipset: EC ITE IT5571VG-I-128/CX
- BIOS Information: AMI BIOS, 128Mbit SPI Flash ROM
- Watchdog Timer: H/W Reset, 1sec. ~ 65535sec and 1sec. or 1min./step
- H/W Status Monitor: Monitoring CPU Temperature, Voltage with Auto Throttling Control
- TPM: TPM2.0
- iAMT: Above Core i5 (selected SKUs)
- SBC: NCM-TGU
- Expansion M.2
- 1 x M.2 Key-M 2280 (PCIe Gen4 x 4)
- 1 x M.2 Key-B 2242/3042/3052 with Internal SIM Slot (PCIe, SATA, USB 2.0)
- 1 x M.2 Key-E 2230 (PCIe, USB 2.0)
- Storage M.2
- 1 x M.2 Key-M 2280 NVMe (PCIe Gen4 x 4)
- 1 x M.2 Key-B 2242 ((PCIe Gen4 x1, SATA3)
- Front I/O
- USB Port: 2 x USB 2.0
- COM Port: 2 x RS232/422/485 (BIOS)
- Audio: 1 x Line-Out, 1 x Mic-In
- Rear I/O
- USB Port: 4 x USB 3.2 Gen.2 (10Gbp/s)
- HDMI: 2 x HDMI 2.0b
- RJ-45: 2 x RJ45
- Display Graphic Chipset
- Intel® Iris® Xe Graphics (i7-1165G7/i5-1135G7)
- Intel® UHD Graphics for 11th Gen Intel® Processors (i3-1115G4)
- Resolution: 2 x HDMI 2.0b: 4096x2304@60Hz
- Audio Codec: RealTek ALC888S-VD2-GR
- Ethernet LAN Chipset
- 1 x Intel® I225-LM
- 1 x Intel® I219-LM
- Specification
- 10/100/1000/2.5 Gigabit (I225-LM)
- 10/100/1000 Gigabit (I219-LM)
CPU:
Intel
Memory:
32GB
DisplayPort:
nein
HDMI:
ja
LVDS:
nein
Temp.:
0...+50
Avalue Technology Inc. entwickelt und produziert industrielle Computerlösungen in Taiwan und international. Zum Portfolio gehören Computer-On-Modules, Single-Board-Computer, Industrial Motherboards, Embedded-, Industrial und Panel PCs als auch Systemlösungen. HY-LINE vertreibt die robusten Produkte zum Einsatz in den Bereichen Healthcare, Digital Signage, Transport und Gaming. Avalue Technology Inc. wurde im Jahr 2000 gegründet und hat seinen Hauptsitz in New Taipei City, Taiwan.
